Clamp-On Desk Organizer - Tool Holder (10-40mm)

This is a clamp-on organizer that hangs off a desk edge. One printed thumbscrew clamps to surfaces from 10 mm to 40 mm thick, so it also fits shelves and workbenches. Pens and scissors sit within reach without taking up desk surface. The body attaches to the bracket with a tapered, cone-shaped dovetail. Instead of lining up a straight dovetail by eye, the taper centers the body as it slides on. Lift it straight up and off to move it. The bracket stays clamped to the desk.   Three parts print: body, bracket and screw. The design uses no metal fasteners.    Dimensions | Width | 144 mm | | Height | 120 mm | | Depth | 78 mm | | Clamp range | 10-40 mm |   Assembly 1. Print the body, bracket, and screw. 2. Thread the screw into the bracket. 3. Clamp the bracket on the desk edge and hand-tighten the screw against the underside. Snug is enough. 4. Line up the body's dovetail slot with the bracket's rail and slide down. The taper centers it. 5. To move or empty it, lift the body straight up and off.   The bin uses the same bracket and clamp: Desk Recycling Bin
