M1128 105mm STRYKER 1:35

Model Details M1128 Stryker 1:35 Scale 3D Project Overview M1128 Stryker 1:35 Scale 3D Printed Model Kit   ItemDescriptionScale1:35FilamentPLAMovable JointsSuspension movement · Wheel rotation · Turret rotation (includes elevation/depression)ConstructionFull multi-part assembly🎨 Parts Color Coding Guide   ColorMeaningActionGreyParts requiring adhesiveGlue locations marked in greenRedMoving partsDo not use glueYellowSubassemblies that move after gluingGlue as instructed, then movableBlueStandard filament connectorsConnect using filament⚙️ Movable Hatch Instructions The kit includes the following movable hatches. Requires threading filament through hinges for attachment: Turret maintenance hatch Shell ejection port Driver's hatch Rear ramp (one-piece print, snap along fold lines) 🔧 Suspension Spring Replacement Method Remove the C-clip from the road wheel Remove the tire Pull out the link rod Remove and replace the spring ⚠️ Important Notes Turret rotation with ramp down: When the rear ramp is at maximum depression, do not rotate the turret rapidly, as this may damage the rear antenna. Maximum gun elevation: To achieve full elevation, the left turret hatch must be opened first. Turret ring lock: The turret ring uses a twist-lock mechanism. Rotate it to the correct position before removal — do not force it apart, as this may damage the locking tabs. 🔭 Upcoming Plans Additional upgrade kits will follow, including:Slat armor kit Explosive Reactive Armor (ERA) kit Stay tuned! Thank you for your support and interest. Happy building! If you have any questions or suggestions, feel free to reach out.
